Diameter: DN40-600

Pressure: PN1.0 / 1.6mpa

Pressure test: BS5163/ISO5208

Temperature: 0-80 ℃

Medium: Water, gas etc.

Diameter: DN40-600

Pressure: PN1.0 / 1.6mpa

Temperature: 0-80 ℃

Valve design: DIN3352-F4

Pressure test: DIN3230

Medium: Water, gas etc.

Product Category: Gate Valve

Diameter: DN40-DN1000

Pressure: PN16/PN25

Gland：DI

Valve design:BS 5163

Face to Face:EN558

Size:1-1/4”~48”

Pressure Rating:PN10-PN64,150LB-600LB,10K-20K

Material:SS304, SS316

Design Standard:API600，BS5153,GB/T122234,JIS B2073

Inspection Standard:API 598,JB/T9092,JIS B2003

Application medium:Oil, Gas, Water, Steam Etc.,

Application Temperature:-29-425℃

Size: DN50-900

Pressure: PN10,PN16，150LB

Suitable temperature: -38~+900℃

Seal type: Hard seal, soft seal

Media: Slurry、Powder、Fiber

Connecting flange: ANSI B16.5、GB/T9113、JB/T79、HG、SH、JIS、DIN、NF、BS

Host materials: WCB、ZG1Cr18Ni9Ti、ZG1Cr18Ni12Mo2Ti、CF8、CF8M、CF3、CF3M

Size Range: DN450 – 1200

Pressure Ratings: PN10 & PN16

Application: Isolate the flow with infrequent operation

Types: Rising/Non-rising stem, Different closing direction

Different flange drillings/Coatings/material

Operation: Stem cap, Handwheel, Gearbox, Electric actuator

Size Range: DN80~DN3200

Deaign standard: EN 593, MSS SP67, API 609, BS5155

Test inspection: API 598, ISO 5208, EN 12266

Application Temperature:-29 °C to 425°C

Pressure Rating: PN10, PN16, CL150, JIS 5K/10K

Suitable medium: Fresh water / Sea water / Salts water / Steam / Gas / Air etc

Size Range: DN80~DN3200

Deaign standard: EN 593, MSS SP67, API 609, BS5155

Test inspection: API 598, ISO 5208, EN 12266

Application Temperature:-29 °C to 425°C

Pressure Rating: PN10, PN16, CL150, JIS 5K/10K

Suitable medium: Fresh water / Sea water / Salts water / Steam / Gas / Air etc

Size Range: DN150 - 3200

Design standard: API609 / AWWA-C504 / BS EN593 / GB/T12238

Test inspection: API598 / BS EN12266 / GB/T 13927

Working temperature: From -20℃ to +220℃

Working pressure: PN10 & PN16 & PN25

Suitable medium: Fresh water / Sea water / Salts water / Steam / Gas / Air etc

Size scope: DN40-DN 1200(DIN/BS)

Design standard: EN 593/API609

Test Inspection: API598

Working temperature: NBR O-70℃. EPDM o-80℃

Working pressure: PN10-16

Suitable medium: Chemicals, air, water, steam, oil, acids, salts ect

Size scope: DN40-DN 1200

Design standard: API609, ANSI16.34, JISB2064, GB T12238

Test inspection: API598

Working temperature: NBR O-70℃. EPDM o-80℃

Working pressure:PN10-16

Suitable medium: Water

Size Range: 2''-44''/DN50-DN1200

Pressure: 5K/10K/150LB

Body Materials: CI/DI/WCB/CF3/ CF3M/CF8/ CF8M

Seat Materials: NBR/EPDM/PTFE/SI

Disc Materials: DI/WCB/CF3/ CF3M/CF8/CF8M/ C954

Stem Materials: 45#/410/ 2Cr13/Cr13/304/316stainless steel
